19 4011000556 U形螺栓JB/ZQ4321-33Zn-Q235A.F U-BOLT JB/ZQ4321-33Zn-Q235A·F N 2
20 4015000162 垫圈GB97.1-10EpZn-300HV WASHER GB97.1-10EpZn-300HV N 6
21 4013000007 螺母GB6170-M10EpZn-8 NUT GB6170-M10EpZn-8 N 6
22 29120011372 固定板 MOUNTED PLATE Y 1
23 4011000447 螺栓GB16674-M10*20EpZn-8.8 BOLT GB16674-M10*20EpZn-8.8 N 4
24 4011000057 螺栓GB5782-M12*165EpZn-8.8 BOLT GB5782-M12*165EpZn-8.8 N 2
25 4015000168 垫圈GB97.1-12EpZn-300HV WASHER GB97.1-12EpZn-300HV N 5
26 4013000011 螺母GB6170-M12EpZn-8 NUT GB6170-M12 EpZn-8 N 5
27 4120001054 多路阀D32A-16 MULTIPLE UNIT VALVE D32A-16 Y 1
28 29120016301 先导胶管（2c） PIPE（2c） Y 1
29 29120007651 接头 JOINT Y 2
30 4041001061 软管LGB128-004250 PIPE LGB128-004250 Y 1
31 4041001189 软管LGB125-003055 HOSE LGB125-003055 Y 1
32 4041001047 组合接头LGB143-01406 CONNECTOR LGB143-01406 Y 1
33 4030000530 O形圈GB3452.1-6.00*1.80G O-RING GB3452.1-6.00*1.80G Y 1
34 4041000027 分体法兰LGB117-312551 FLANGE LGB117312551 Y 2
35 4041000716 防尘盖LGB134-01255 DUST-PREVENTION CAP Y 2
36 29120007671 管夹 CLAMP Y 2
1 4120001054004 端盖D32-1 END CAP N 3
2 4120001054005 动臂阀杆D32-2 VALVE STEM N 1
3 4120001054006 阀体D32-4 VALVE BODY N 1
4 4030000608 PO形圈GB1235-60*3.1 O-RING GB1235-60*3.1 Y 3
5 4120001054007 弹簧D32-8 SPRING N 3
6 4015000168 垫圈GB97.1-12EpZn-300HV WASHER GB97.1-12EpZn-300HV N 3
7 4011000087 螺栓GB5783-M12*20EpZn-8.8 BOLT GB5783-M12*20EpZn-8.8 N 3
8 4120001054009 端盖D32-5 END CAP N 3
9 4120001054010 弹簧D32-7 SPRING N 3
10 4015000025 垫圈GB93-10-65Mn WASHER GB93-10-65Mn N 12
11 4014000217 螺钉GB70.1-M10*100EpZn-8.8 SCREW GB70.1-M10*100EpZn-8.8 N 6
12 4120001054012 弹簧座D32-6 SPRING SEAT N 6
13 7200000446 O型圈 O-RING N 2
14 4120001054014 补油阀盖D32-13 FLOAT TRAP VALVE BODY N 1
15 4120001054015 弹簧D32-14 SPRING N 1
16 4120001054016 补油阀D32-15 VALVE CORE N 1
17 4120001054017 螺塞D32A-10 PLUG N 3
18 4120001054018 O形圈8.9*2.3 O-RING 8.9*2.3 N 3
19 7200001075 O形圈50*3.1 O-RING 50*3.1 N 4
20 4120001054020 辅助阀杆D32A-11 VALVE STEM N 1
21 4030000706 O形圈GB1235-44*3.5 O-RING GB1235-44*3.5 N 4
22 4120001054022 阀盖D32-19 CHECK VALVE BODY N 4
23 4120001054023 弹簧D32-16 SPRING N 4
24 4120001054024 单向阀D32-17 CHECK VALVE N 4
25 4030000707 O形圈GB1235-55*3.1 O-RING GB1235-55*3.1 N 1
26 4120001054026 转斗阀杆D32-12 VALVE STEM N 1
27 4014000115 螺钉GB70.1-M10*1.5*45EpZn-8.8 SCREW GB70.1-M10*1.5*45EpZn-8.8 N 6
28 4120001054003 小腔过载补油阀 OVERLOAD VALVE Y 1
29 4120001054002 大腔过载补油阀 OVERLOAD VALVE Y 1
30 4120001054029 堵头D32A-20 CHOKE PLUG N 1
31 4030000149 O形圈GB1235-35*3.5 O-RING GB1235-35*3.5 Y 1
32 4120001054030 螺栓D32A-21 BOLT N 5
33 4120001054001 安全阀D32.2a-00 RELIEF VALVE Y 1
34 4120001054031 阀体D32A-22 VALVE BODY N 1
35 4120001054032 堵头D32A-23 CHOKE PLUG N 2
36 4120001054033 阀杆接头D32-21 VALVE STEM JOINT N 3
37 4120001054034 调整垫片D32-9 ADJUSTING SHIM N 1
38 4120002303004 螺塞D32-3 PLUG D32-3 N 3
39 4030000011 O形圈GB1235-20*2.4 O-RING GB1235-20*2.4 Y 3
