SDLG LG938L LG956L LG958LWHEEL LOADER SPARE PARTS:
电气系统 ELECTRIC SYSTEM
1 29370009571 启动马达线 LINE FROM SWITCH TO MOTOR Y 1
2 4011000461 螺栓GB16674-M8*16EpZn-8.8 BOLT GB16674-M8*16EpZn-8.8 N 16
3 29370014291 电瓶线A50*350 BATTERY WIRE A50*350 Y 1
4 4130000427 电源开关K01K18-A POWER SWITCH K01K18-A Y 1
5 29370014261 电瓶线P50*150 BATTERY WIRE P50*150 Y 1
6 4130000057 蓄电池6-QW-120B BATTERY 6-QW-120B Y 2
7 29370013101 蓄电池串联线 BATTERY CABLE Y 1
8 29310011841 卡子胶条 DIP RUBBER BAR Y 2
9 29370015301 继电器保护盒 RELAY PROTECT BOX Y 1
10 4014000024 螺钉GB818-M6*10EpZn-4.8 SCREW GB818-M6*10EpZn-4.8 N 4
11 4015000207 垫圈GB97.1-6EpZn-300HV WASHER GB97.1-6EpZn-300HV N 6
12 4015000035 垫圈GB93-6-65Mn WASHER GB93-6-65Mn N 6
13 29370015291 继电器固定板 RELAY FIXATION PLANT Y 1
14 4130000694 接触器MZJ-100A/006 CONTACTOR MZJ-100A/006 Y 2
15 4014000061 螺钉GB818-M4*10EpZn-4.8 SCREW GB818-M4*10EpZn-4.8 N 4
16 4015000135 垫圈GB97.1-4EpZn-300HV WASHER GB97.1-4EpZn-300HV N 4
17 4015000033 垫圈GB93-4-65Mn WASHER GB93-4-65Mn N 4
18 4190000020 扎丝LG13-ZS4*250 CLIP LG13-ZS4*250 Y 84
19 26370001911 管夹 CLAMP Y 5
20 4130000009 双音盆形喇叭DL125-24V ELECTRIC HORN DL125-24V Y 1
21 4011000152 螺栓GB16674-M6*10EpZn-8.8 BOLT GB16674-M6*10EpZn-8.8 N 2
22 4130000542 前左组合灯LFLDH4-24V LEFT FRONT HEAD LAMP LFLDH4-24V Y 1
23 29370014021 前车架线束 FRONT BODY WIRING HARNESS Y 1
24 4130000543 前右组合灯LFRDH4-24V RIGHT FRONT HEAD LAMP LFRDH4-24V Y 1
25 29370015591 启动继电器固定板 FIXED PLATE OF STARTUP RELAY Y 1
26 4130000874 启动继电器SW030A3509-2 ENABLE RELAY SW030A3509-2 Y 1
27 4014000026 螺钉GB818-M6*16EpZn-4.8 SCREW GB818-M6*16EpZn-4.8 N 2
28 4130000329 隔膜式压力开关0166-40404-1-016 PRESS SWITCH 0166-40404-1-016 Y 1
29 4130000326 接近开关WEK200-IV ADJACENT SWITCH Y 1
30 4130000278 隔膜式压力开关310-LGK DISSEPIMENT PRESSURE SWITCH310-LGK Y 1
31 29370015121 后车架线束 BODY WIRING HARNESS Y 1
32 4130000213 后尾灯LRTD－24V REAR LAMP LRTD－24V Y 2
33 4130000544 后大灯SPH4-1031 REAR LARGE LAMP SPH4-1031 Y 2
34 29370009531 后罩线束 COVER HARNESS Y 1
35 4130000615 前照灯QZD-1 FORWARD LIGHTING QZD-1 Y 4
36 4130000121 倒车蜂鸣器KSHM-12F4 ANNUNCIATOR KSHM-12F4 Y 1
37 29370015141 仪表台线束总成 PANEL HARNESS ASSEMBLY Y 1
38 4130000869 中间继电器024-1Z6GD2 AUXILIARY RELAY 024-1Z6GD2 Y 6
39 4014000048 螺钉GB818-M5*12EpZn-4.8 SCREW GB818-M5*12EpZn-4.8 N 6
40 4015000110 垫圈GB97.1-5EpZn-300HV WASHER GB97.1-5EpZn-300HV N 6
41 4015000034 垫圈GB93-5-65Mn WASHER GB93-5-65Mn N 6
42 29370015351 仪表盘总成Y956CAT PANEL ASSEMBLY Y956CAT Y 1
43 29370014681 仪表台总成 INSTRUMENT DESK ASSEMBLY N 1
44 4130000498 侧边单框架JK931-01CKJ SIDE FRAME JK931-01CKJ Y 6
45 4130000496 盖板JK931-01GB CAP JK931-01GB Y 13
46 4130000497 中间单框架JK931-01ZKJ MIDDLE FRAME JK931-01ZKJ Y 7
47 4130000060 手制动开关LA39-01Z HAND BRAKE SWITCH LA39-01Z Y 1
SDLG L956F WHEEL LOADER SPARE PARTS:
1 4011001423 螺栓GB16674.1-M6*10f1Znyc-8.8-480 Bolt 2
2 4130002557 盆型喇叭DL125-100L-01 Horn Y
3 4130000542 前左组合灯LFLDH4-24V Lamp Y 1
4 29410001961 接近开关过渡线束 Cable hattess Y 1
5 29410001701 前车架线束 Wiring harness Y 1
6 4011001297 螺栓GB16674.1-M8*16f1Znvc-8.8-48 Screw Y 9
7 4190001838 扎丝RTGB-370HD-S Cibletie Y 5
8 4130000543 前右组合灯LFRDH4-24V Lamp 1
9 4130002556 盆型喇叭DL125-100H-01 Horn
10 4130001028 接近开关I7-D10B1/DC Fosition switch Y 2
11 4130001006 CLIP 1027-003-1200 alip Y 2
12 29140016461 举升限位支架 Bracket Y
13 4011001241 螺栓GB5783-M12*25f1Znuc-8.8-480 Screw Y 2
14 4015000128 华图GB97.1-12f1Znvc-300HV-480 Washer Y 2
15 4041002411 管夹LGB169-A15*10 Clamp Y 3
16 4041002410 管夹LGB169-112*10 Clamp 6
